Fengfang Electronic Battery Tester, 60W Constant Current Circuit DC 12V TE553 Load Battery Discharge Capacity Testing Detection Meter

Specifications: Operating modes: Single mode constant current (CC) Power: 60W Power supply voltage: DC 12V Power supply current: 0.5-5A Discharge current: 0.20 - 9.99A stepper 0.1A or 0.01A Discharge current maximum error: 0.01A - 0.7% The maximum capacity test error: 0.5A - 2.5%, 2A - 1.5%, more than 5A - 1.2% Offline/Termination Voltage Range: 1.0-25.0V stepping 1V or 0.1V Discharge voltage : 1.00-30.00V Maximum voltage measurement error: 1% ¡À0.02V Maximum power: 60W (Automatically limits the maximum current. For example, when input is 12V, the current will be below 5A.) Maximum battery test statistic: 999.9Ah or 9999Wh (stops when one of them achieve the value) Fan control : Intelligent Control Board Dimension: 100 x 70 x 57mm (the Fan protrudes about 12mm) Positioning hole position: 60 x 88mm Positioning hole diameter: 3.2mm with 5mm brass pedestal already installed Notes: 1. The wires and cables are not included. 2. During the "Battery capacity testing", the discharge current can adjust at any time. If you want to reset the terminal voltage, please press Start-Stop switch to stop discharging.(It will go back to setting, the data will not be losing. If you want to delete all the data, please press and hold Start-Stop switch until it shows 0.000Ah) 3. The tester features an automatic power-down save function, it will automatically save the pre-set data and the operating status, restore them after the circuit recovery. Package includes: 1 x Constant Current Electronic Load 60W Battery Discharge Capacity Tester
