Honeywell ML6161A2009 Damper Actuator

The Honeywell ML6161 Direct-Coupled, Non-Spring Return Damper Actuators are used to control dampers in applications such as variable air volume (VAV) terminal units, and for mounting on ball valves. Features: . Superior A/C synchronous submotor for consistent timing and actuator longevity. . Eliminate need for limit switches or mechanical stops by providing magnetic coupling. . All models include manual declutch lever, and bag assembly with two minimum position setscrews. . Mount directly on 3/8" or 1/2" square or round damper shaft. . Selectable 45, 60, and 90 stroke in either clockwise or counterclockwise direction. Specifications: Description: Non-Spring Return Direct Coupled Actuator Type of Control: Electric Feedback: With accessory only Electrical Connections: Screw terminals Stroke Max (deg, in): Adjustable w/accessory (30, 60, or 90 deg) External Aux. Switches Available: Yes Power Consumption: 2.04 VA Dimensions: 5-9/16"H x 3-3/8"W x 2-1/16"D (141 mm H x 86
